Shperical Roller Bearing 22260 22264 22268 CC/W33
| Designations | Boundary Dimensions (mm) |
Basic Load Ratings (kN) |
Speed Ratings | |||||
| d | D | B | r1.2min | Cr | Cor | Grease | Oil | |
| 22260CC/W33 | 300 | 540 | 140 | 5 | 2640 | 4250 | 600 | 750 |
| 22264CC/W33 | 320 | 580 | 150 | 5 | 2990 | 4850 | 530 | 670 |
| 22268CC/W33 | 340 | 620 | 165 | 6 | 3450 | 5600 | 430 | 560 |
| Designations | Abutment and Fillet Dimensions | Calculation Factors | Mass (kg) |
|||||
| damin | damax | ramax | e | Y1 | Y2 | Y0 | Refer. | |
| 22260CC/W33 | 322 | 518 | 4 | 0.25 | 2.7 | 4 | 2.6 | 139 |
| 22264CC/W33 | 342 | 558 | 4 | 0.26 | 2.6 | 3.9 | 2.6 | 174 |
| 22268CC/W33 | 368 | 592 | 5 | 0.28 | 2.4 | 3.6 | 2.4 | 226 |
