Spherical Roller Bearing 23252 23256 CC/W33
| Designations | Boundary Dimensions (mm) |
Basic Load Ratings (kN) |
Speed Ratings | |||||
| d | D | B | r1.2min | Cr | Cor | Grease | Oil | |
| 23252CC/W33 | 260 | 480 | 174 | 5 | 2740 | 4550 | 560 | 750 |
| 23256CC/W33 | 280 | 500 | 176 | 5 | 2880 | 4900 | 530 | 670 |
| Designations | Abutment and Fillet Dimensions | Calculation Factors | Mass (kg) |
|||||
| damin | damax | ramax | e | Y1 | Y2 | Y0 | Refer. | |
| 23252CC/W33 | 282 | 458 | 4 | 0.37 | 1.8 | 2.7 | 1.8 | 137 |
| 23256CC/W33 | 302 | 478 | 4 | 0.35 | 1.9 | 2.9 | 1.9 | 147 |
