Withdrawal Sleeve AH3120 AH3122 AH3124
Designations |
screw thread |
Boundary Dimensions |
Lock nut |
Appropriate Bearing(s) |
W.t |
||||
d |
d1 |
B |
B4 |
Spherical roller bearing |
KG |
||||
AH3120 |
M110×2 |
100 |
95 |
64 |
68 |
KM22 |
23120K |
– |
0.66 |
AH3122 |
M 120×2 |
110 |
105 |
68 |
72 |
KM24 |
23122K |
22222K |
0.76 |
AH3124 |
M 130×2 |
120 |
115 |
75 |
79 |
KM26 |
23124K |
22224K |
0.94 |
AH3126 |
M 140×2 |
130 |
125 |
78 |
82 |
KM28 |
23126K |
22226K |
1.10 |
AH3128 |
M 150×2 |
140 |
135 |
83 |
8B |
KM30 |
23128K |
22228K |
1.30 |
AHX3130 |
M 160×3 |
150 |
145 |
96 |
101 |
KM32 |
23130K |
22230K |
1.70 |
AHX3132 |
M 170×3 |
160 |
150 |
103 |
108 |
KM34 |
23132K |
22232K |
3.00 |
AHX3134 |
M 180×3 |
170 |
160 |
104 |
109 |
KM36 |
23134K |
22234K |
3.20 |
AHX3136 |
M 190×3 |
180 |
170 |
116 |
122 |
KM38 |
23136K |
– |
3.90 |
AHX3138 |
M 200×3 |
190 |
180 |
125 |
131 |
KM40 |
23138K |
– |
4.50 |
AH3140 |
Tr 220×4 |
200 |
190 |
134 |
140 |
HM44 |
23140K |
– |
5.65 |
AH3144 |
Tr 240×4 |
220 |
200 |
145 |
151 |
HM48 |
23144K |
– |
9.30 |
AH3148 |
Tr 260×4 |
240 |
220 |
154 |
61 |
HM52 |
23148K |
– |
12.0 |
AHX3152 |
Tr 280×4 |
260 |
240 |
172 |
179 |
HM56 |
23152K |
– |
15.0 |
AHX3156 |
Tr 300×4 |
280 |
260 |
175 |
183 |
HM60 |
23156K |
– |
16.7 |
AHX3160 |
Tr 320×5 |
300 |
280 |
192 |
200 |
HM64 |
23160K |
– |
19.8 |
AHX3164 |
Tr 340×5 |
320 |
300 |
209 |
217 |
HM68 |
23164K |
– |
23.3 |
AHX3168 |
Tr 360×5 |
340 |
320 |
225 |
234 |
HM72 |
23168K |
– |
27.6 |
AHX3172 |
Tr380×5 |
380 |
340 |
229 |
238 |
HM76 |
23172K |
– |
29.8 |
AHX3176 |
Tr 400×5 |
380 |
360 |
232 |
242 |
HM80 |
23176K |
– |
32.0 |
AHX3180 |
Tr 420×5 |
400 |
380 |
240 |
250 |
H84 |
23180K |
– |
36.0 |
AHX3184 |
Tr 440×5 |
420 |
400 |
266 |
276 |
HM88 |
23184K |
– |
43.0 |
AHX3188 |
Tr 460×5 |
440 |
420 |
270 |
281 |
HM92 |
23188K |
– |
46.0 |
AHX3192 |
Tr 480×5 |
460 |
440 |
285 |
296 |
HM96 |
23192K |
– |
51.5 |
AHX3196 |
Tr 500×5 |
480 |
460 |
295 |
307 |
HMI500 |
23196K |
– |
56.0 |
